Review the high frequencies of the inca bone in East Asian hominins
-
摘要:
印加骨作为一项重要的非测量性状，主要由遗传因素调控，对于解读现代人群的扩散和分布具有重要意义。但在印加骨所在区域还存在另一类型的缝间骨即前顶间骨，前人在研究中常将两者相混淆。文章通过观察中国古人类头骨（直立人4例，早期智人4例和早期现代人3例）中的缝间骨形态，依据其下缘横向骨缝的位置特征，对这些骨骼进行再次鉴定分类。结果表明北京直立人11号头骨和石沟枕骨所属个体具有印加骨，北京直立人12号头骨、大荔头骨和穿洞2号头骨具有前顶间骨，丽江头骨具有人字点骨。而北京直立人2号和10号头骨的下缘横向骨缝处于枕骨圆枕区域内或下侧，表明这两处骨缝并非是枕横缝，即北京直立人2号和10号头骨不具有印加骨。丁村和许家窑古人类顶骨后上角的缺刻特征，更可能与额外骨化中心的出现（人字点骨或前顶间骨）相关，而非是印加骨。总之，目前的古人类化石证据表明印加骨在中国古人类出现次数并不多。
Abstract:The inca bones, an important discrete trait, is pivotal to exploring the origin, diffusion and distribution of modern humans. However, another suture bone known as pre-interparietal bone is also located in the interparietal region of the occipital bone, which results in a confusion with the inca bone in previous studies. Therefore, we aimed to take a detailed description of the inca bones appeared in the Chinese hominin fossils and if possible, to make a reasonable identification and classification. We used 11 specimens mainly from the Institute of Vertebrate Paleontology and Paleoanthropology and Folk Custom Museum of Dingcun for this study. It contains 4 Homo erectus skulls (Homo erectus pekinensis Skull Ⅱ, Ⅹ, Ⅺ and Ⅻ), 4 early Homo sapiens specimens (Dali skull, Dingcun parietal bone, Xujiayao Ⅵ and Ⅹ parietal bones)and 3 early modern human specimens (Shigou occipital bone, Chuangdong Ⅱ skull and Lijiang skull).
In Homo erectus pekinensis Skull Ⅺ, an accessory transverse suture separates the superior part of the occipital planum form remainder, which forms a large triangular bone. The transverse suture in Shigou fossil is approximately 52.0 mm at the superior border of the occipital squama just above the highest nuchal line. Considering location and size of the transverse suture, these two individuals display the inca bones.
Weidenreich[11] (1943)stated that Homo erectus pekinensis Skull Ⅱ preserves a fused mendosal suture presented on the medial side of the asterion region, while Homo erectus pekinensis Skull Ⅹ displays an accessory transverse suture which entirely or partly separates a genuine inca bone with the remaining bone. The mendosal suture refers to an accessory suture of the occipital bone originated from the asterion region, which usually runs horizontally just above the superior nuchal line. If we accepted the view that the occipital torus can develop into the superior and highest nuchal lines, combined with the position of transverse suture, it seems that the inca bones cannot appear in the Skull Ⅱ and Skull Ⅹ.
In Homo erectus pekinensis Ⅻ, Dali and Chuangdong Ⅱ skulls, we found the sutural bones donot beyond the medial one-third of the lambdoid suture, and the inferior margins are significantly above the highest nuchal line. Thus, these three bones can be classified as pre-interparietal bone. The missed posterosuperior portion showed in Dingcun and Xujiayao parietal bones, which may be related to the ossicle at lambda or pre-interparietal bone, is affected by the appearance of extra ossification centers that disturbs the parietal development. In addition, Lijiang skull displays an ossicle at lambda.
In sum, it seems that the inca bone just appears in the Homo erectus pekinensis Ⅺ skull and Shigou hominin.
-
Key words:
- East Asian hominins /
- Inca bone /
- suture /
- ossification center
-
-
图 2
北京直立人2 (a)、10 (b)、11 (c)和12 (d)号头骨背侧观
Figure 2.
Posteriorview of Homo erectus pekinensis Skull Ⅱ (a), Ⅹ (b), Ⅺ (c)and Ⅻ (d):upper image was quoted from Weidenreich[11]; lower image was photoed from the models collected in IVPP. As Weidenreich[11] stated, the arrows displayed in (a) and (b) show the mendosal suture, while the arrows displayed in (c) and (d) show the inca bone
图 3
假缝示意图(a，引自Tubbs等[16])、北京直立人10号头骨左侧(b)和右侧(c)假缝(下侧箭头指示假缝，上侧箭头指示人字缝)以及北京直立人11号头骨中印加骨形态(d)(下侧箭头指示枕横缝，上侧箭头指示人字缝)
Figure 3.
Exampleof the mendosal suture(a, Tubbs, et al. [16]), the left(b) and right(c) mendosal sutures displayed in the Homo erectus pekinensis Skull Ⅹ:infer arrows show the mendosal suture and superior arrow shows the lambdoidal suture. The inca bone displayed in Homo erectus pekinensis Skull Ⅺ (d), infer arrow shows the transverse occipital suture and superior arrows show the lambdoidal sutures
图 4
大荔头骨(a)、丁村顶骨(b)、许家窑Ⅵ顶骨(c)、许家窑Ⅹ顶骨(d)、石沟枕骨(e)、穿洞2号头骨(f)[15]、丽江头骨(g)和Olenjy Ostrow头骨(h)
Figure 4.
Viewof Dali skull (a), Dingcun parietal bone (b), Xujiayao Ⅵ parietal bone (c), Xujiayao Ⅹ parietal bone (d), Shigou occipital bone (e), Chuangdong Ⅱ skull (f)[15], Lijiang skull(g) and Olenjy Ostrow skull (h)
-
[1] Bhanu P S, Sankar K D. Interparietal and pre-interparietal bones in the population of south coastal Andhra Pradesh, India[J]. Folia Morphologica, 2011, 70(3):185-190.
[2] Carolineberry A, Berry R J. Epigenetic variation in the human cranium[J]. Journal of Anatomy, 1967, 101(Pt2):361-379. http://d.old.wanfangdata.com.cn/OAPaper/oai_pubmedcentral.nih.gov_1270890
[3] Srivastava H C. Ossification of the membranous portion of the squamous part of the occipital bone in man[J]. Journal of Anatomy, 1992, 180(Pt2):219-224. http://d.old.wanfangdata.com.cn/OAPaper/oai_pubmedcentral.nih.gov_1259666
[4] Matsumura G, Uchiumi T, Kida K, et al. Developmental studies on the interparietal part of the human occipital squama[J]. Journal of Anatomy, 1993, 182(Pt2):197-204. http://d.old.wanfangdata.com.cn/OAPaper/oai_pubmedcentral.nih.gov_1259830
[5] 杜抱朴.人字点骨、印加骨和前顶间骨鉴定分类辨析[J].现代人类学, 2017, 5(4):47-53. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=HANS201711240205
Du Baopu. Discriminate analysis of the ossicle at lambda, inca bone and pre-interparietal bone[J]. Modern Anthropology, 2017, 5(4):47-53. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=HANS201711240205
[6] Saxena S K, Chowdhary D S, Jain S P. Interparietal bones in Nigerian skulls[J]. Journal of Anatomy, 1986, 144:235-237. http://d.old.wanfangdata.com.cn/OAPaper/oai_pubmedcentral.nih.gov_1166477
[7] Gopinathan K. A rare anomaly of 5 ossicles in the pre-interparietal part of the squamous occipital bone in North Indians[J]. Journal of Anatomy, 1992, 180(Pt1):201-202. http://d.old.wanfangdata.com.cn/OAPaper/oai_pubmedcentral.nih.gov_1259626
[8] 赖育鹏, 贺伦, 孙建永.颅骨顶间骨变异一例[J].解剖学杂志, 2017, 40(2):180. doi: 10.3969/j.issn.1001-1633.2017.02.039
Lai Yupeng, He Lun, Sun Jianyong. One case for the interparietal bone variation[J]. Chinese Journal of Anatomy, 2017, 40(2): 180. doi: 10.3969/j.issn.1001-1633.2017.02.039
[9] Hanihara T, Ishida H. Frequency variations of discrete cranial traits in major human populations. Ⅰ. Supernumerary ossicle variations[J]. Journal of Anatomy, 2001, 198(Pt6):689-706.
[10] Dart R A. The Makapansgat protohuman Australopithecus prometheus[J]. American Journal of Physical Anthropology, 1948, 6(3):259-284. doi: 10.1002/(ISSN)1096-8644
[11] Weidenreich F. The skull of Sinanthropus pekinensis:A comparative study of a primitive hominid skull[J]. Palaeontologia Sinica, 1943, New Series D (10):1-486.
[12] 吴新智.中国远古人类的进化[J].人类学学报, 1990, 9(4): 312-321. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=QK000002479900
Wu Xinzhi. The evolution of humankind in China[J]. Acta Anthropologica Sinica, 1990, 9(4):312-321. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=QK000002479900
[13] Lahr M M. The multiregional model of modern human origins:A reassessment of its morphological basis[J]. Journal of Human Evolution, 1994, 26(1):23-56. doi: 10.1006/jhev.1994.1003
[14] Bae C J. The late Middle Pleistocene hominin fossil record of eastern Asia:Synthesis and review[J]. American Journal of Physical Anthropology, 2010, 143(S51):75-93. doi: 10.1002/ajpa.v143:51+
[15] 刘武, 吴秀杰, 邢松, 等.中国古人类化石[M].北京:科学出版社, 2014:312.
Liu Wu, Wu Xiujie, Xing Song, et al. Human Fossils in China[M]. Beijing:Science Press, 2014:312.
[16] Tubbs R S, Salter E G, Oakes W J. Does the mendosal suture exist in the adult?[J]. Clinical Anatomy, 2007, 20(2):124-125. doi: 10.1002/(ISSN)1098-2353
[17] 刘俊刚, 李欣, 王春祥, 等.儿童枕骨鳞部正常解剖, 解剖变异及骨折的三维CT特征[J].中华放射学杂志, 2013, 47(4):361-363. doi: 10.3760/cma.j.issn.1005-1201.2013.04.016
Liu Jungang, Li Xin, Wang Chunxiang, et al. Three-dimensional CT features of occipital squama normal anatomy, anatomic variations and fractures[J]. Chinese Journal of Radiology, 2013, 47(4):361-363. doi: 10.3760/cma.j.issn.1005-1201.2013.04.016
[18] Mann K S, Chan K H, Yue C P. Skull fractures in children:Their assessment in relation to developmental skull changes and acute intracranial hematomas[J]. Child's Nervous System, 1986, 2(5): 258-261.
[19] Antón S C. Developmental age and taxonomic affinity of the Mojokerto child, Java, Indonesia[J]. American Journal of Physical Anthropology, 1997, 102(4):497-514. doi: 10.1002/(ISSN)1096-8644
[20] 刘武, Mbua E, 吴秀杰, 等.中国与非洲近代-现代人类某些颅骨特征的对比及其意义[J].人类学学报, 2003, 22(2):89-104. doi: 10.3969/j.issn.1000-3193.2003.02.001
Liu Wu, Mbua E, Wu Xiujie, et al. The comparison of cranial features between Chinese and African Holocene humans, and their implications[J]. Acta Anthropologica Sinica, 2003, 22(2):89-104. doi: 10.3969/j.issn.1000-3193.2003.02.001
[21] Thoma A. Some notes on Wolpoff's notes on the Vértesszølløs occipital[J]. Journal of Human Evolution, 1978, 7(4):323-324. doi: 10.1016/S0047-2484(78)80073-6
[22] 吴新智.大荔颅骨在人类进化中的位置[J].人类学学报, 2014, 33(4):405-426. http://d.old.wanfangdata.com.cn/Periodical/rlxxb201404001
Wu Xinzhi. The place of Dali cranium in human evolution[J]. Acta Anthropologica Sinica, 2014, 33(4):405-426. http://d.old.wanfangdata.com.cn/Periodical/rlxxb201404001
[23] 吴新智.中国的早期智人[M] //吴汝康, 吴新智, 张森水.中国远古人类.北京: 科学出版社, 1989: 24-41.
Wu Xinzhi. Early Homo sapiens from China[M] // Wu Rukang, Wu Xinzhi, Zhang Senshui. Early Humankind in China. Beijing: Science Press, 1989: 24-41.
[24] 云南省博物馆.云南丽江人类头骨的初步研究[J].古脊椎动物与古人类, 1977, 15(2):157-161. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=QK000005217607
Yunnan Provincial Museum. Preliminary study on the human cranium from Lijiang, Yunnan[J]. Vertebrata PalAsiatica, 1977, 15(2):157-161. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=QK000005217607
[25] Boaz N T, Howell Clark F. A gracile hominid cranium from upper member G of the Shungura formation, Ethiopia[J]. American Journal of Physical Anthropology, 1977, 46(1):93-108. doi: 10.1002/(ISSN)1096-8644
[26] Mizoguchi Y. Typicality probabilities of Late Pleistocene human fossils from East Asia, Southeast Asia, and Australia:Implications for the Jomon population in Japan[J]. Anthropological Science, 2011, 119(2):99-111. doi: 10.1537/ase.090330
[27] Hanihara T, Ishida H. Os incae:Variation in frequency in major human population groups[J]. Journal of Anatomy, 2001, 198(2): 137-152. doi: 10.1046/j.1469-7580.2001.19820137.x
[28] Wolpoff M H. Some notes on the Vértesszølløs occipital[J]. American Journal of Physical Anthropology, 1977, 47(3): 357-363. doi: 10.1002/(ISSN)1096-8644
[29] Clarke R J. The Ndutu cranium and the origin of Homo sapiens[J]. Journal of Human Evolution, 1990, 19(6):699-736.
[30] Stringer C B, Howell F C, Melentis J K. The significance of the fossil hominid skull from Petralona, Greece[J]. Journal of Archaeological Science, 1979, 6(3):235-253. doi: 10.1016/0305-4403(79)90002-5
[31] Di Ieva A, Bruner E, Davidson J, et al. Cranial sutures:A multidisciplinary review[J]. Child's Nervous System, 2013, 29(6):893-905. doi: 10.1007/s00381-013-2061-4
[32] Wolpoff M H, Wu X Z, Thorne A G. Modern Homo sapiens origins: A general theory of hominid evolution involving the fossil evidence from East Asia[M]//Smith F H, Spencer F. The Origins of Modern Humans: A World Survey of the Fossil Evidence. New York: Alan R. Liss, 1984: 411-483.
-
